Functional Features
The interior of the oven is made of mirror – faced stainless steel, and the exterior is made of high – quality steel plate.
It uses a micro – computer PID temperature controller with over – temperature deviation protection and digital display, with timing function, precise and reliable temperature control.
The hot – air circulation system is composed of a fan that can operate continuously at high temperatures and suitable air ducts, improving the temperature uniformity in the working chamber.
It uses a new – type composite silicone seal, which can run at high temperatures for a long time, has a long service life, and is easy to replace.
The intake and exhaust air volume in the oven can be adjusted from the control panel.
Technical Parameter
| Power Supply | Single – phase AC220V ± 10%, frequency 50HZ, power about 1.1KW |
| Temperature Control Range | RT + 10 ~ 250°C |
| Constant – Temperature Fluctuation | ± 1.0°C |
| Temperature Resolution | 0.1°C |
| Temperature Uniformity | ± 3% (test point at 100°C) |
| Inner Chamber Size | W420×D395×H350mm |
| Equipment Size | W700×D615×H520mm |
