Manual Stacking Holder for Single-Layer or Multiple-Layer Pouch Cells – MSK-111A-PF4662

Application range:

MSK-111A-PF4662 is a device mainly used in the single-layer stacking process of lithium-ion battery pole sheets. This device allows manual placement of separators and pole sheet, with Z-shaped manual stacking and auxiliary positioning by the fixture to ensure positioning accuracy. The groove design under the battery cell facilitates material taking. It features high stacking efficiency and good stacking neatness, and can be customized with special fixtures according to battery sizes, making it an ideal choice for R&D sample production and small-batch trial production equipment.

Model:

MSK-111A-PF4662

Dimension:

L250mm x W83mm x H129mm

Net weight:

About 1.3kg

Categories: ,
Share your love
Share your love
Get Your Quotation

Features

  • Z-shaped manual stacking with auxiliary positioning for separator position.
  • Manual placement of pole sheets and separators, with auxiliary compression by the fixture to ensure stacking neatness.
  • Groove design under the battery cell for easy material taking.
  • Special fixtures can be customized according to battery sizes.
  • The desktop-type design is compact and convenient, with simple operation and easy maintenance.

Specifications

Stacking Accuracy Neatness ±0.5mm
Stacking Size 30～80mm L, 45mm W (size of negative pole sheet, excluding tabs); special fixtures can be customized according to the dimensions provided by customers
Stacking Thickness Max. 3mm
Standard Size L62mm*W46mm
Dimension L250mm×W83mm×H129mm
Weight About 1.3kg
