Functional Features
7 – inch touch – screen operation, with fashionable and convenient human – machine interface.
It has two test modes: friction coefficient and 180° peel.
With a wide range and high – precision temperature control device, it can easily achieve sample tests at different temperatures.
It has stepless speed change and multiple – gear speed adjustment to meet different customer needs.
The sliding block is automatically released to ensure the precise residence time of the sliding block and improve the repeatability of test data.
The instrument meets various tests of GB, ISO, and ASTM.
Both the instrument test platform and test sliding blocks have undergone demagnetization treatment and residual magnetism detection, effectively reducing system test errors.
The system is jointly controlled by a computer and a micro – processor, facilitating users to quickly perform test operations.
Professional software provides test result curve superposition statistical analysis, accurately and intuitively presenting test results to users.
Equipped with a USB interface, professional test control software, and capable of controlling the instrument to complete various tests through software.
The instrument complies with multiple national and international standards: GB/T 10006, GB/T 2790, GB/T 2791, GB/T 2792, ISO 8295, ISO 8510 – 2, ASTM D1894, ASTM D4917, ASTM D3330, TAPPI T816, TAPPI T549.
Technical Parameters
| Power Requirement | AC220V ±10%, 50Hz/60Hz, single phase
200W |
| Working Environment | The recommended environmental conditions are: temperature ranging from 25 ± 3℃, humidity between 30% and 90%, without vibration or electromagnetic interference. |
| Peel Strength Test | 0-5 N
0-10 N 0-30 N |
| Sliding Block Mass
|
Standard block with 200 g (other mass of 100 g, 500 g, 1000 g, 1814 g, and 2000 g are available upon request ) |
| Testing Speed | 1-600 mm/min |
| Dimension | L830mm×W390mm×H250mm |
| Weight | 33KG |
