Features
- Hydraulic pressurization with adjustable pressure;
- PLC control with digital touchscreen parameter setting;
- Upper and lower platen parallelism ≤10 μm;
- Dual start buttons with light curtain protection for safe and reliable operation;
- Resistive heaters deliver uniform and accurate surface temperature control and are easy to replace;
- Pressure platens are made of imported high-temperature-resistant die steel, providing high precision, low thermal deformation, and minimal hardness decay.
Specifications
| Power Supply | Single-phase AC 220V ±10%, 50 Hz (AC 110V/60 Hz customizable); Power: 5 kW |
| Operating Environment | Recommended ambient temperature 25 ±3 °C, humidity 30–90% RH, free from vibration and electromagnetic interference |
| Working Pressure | Max: 10 T; Accuracy: ±25 kg |
| Platen Accuracy | Upper and lower platen parallelism ≤10 μm |
| Pressure Stroke | Pre-pressing: 0–80 mm; Boost pressing: 15 mm |
| Pressing Direction | Pre-pressing: top to bottom; Boost pressing: bottom to top |
| Heating Temperature | Max: 200 °C; Accuracy: ±3 °C |
| Hot-Pressing Area | Max: L 120 mm × W 120 mm |
| Die Opening Height | Max: 80 mm |
| Platen Material | Imported high-temperature-resistant die steel, hardness HRC 60–62 (hardness decay <8% after heating at 200 °C) |
| Holding Time | Settable via touchscreen |
| Equipment Dimensions | Main unit: L 520 mm × W 380 mm × H 640 mm |
| Weight | Approx. 115 kg |
