Features
- Robust & Safe Construction: Features a fully explosion-proof design concept driven by a durable DC Brushless Motor, ensuring spark-free and maintenance-free operation.
- Comprehensive Safety Protection: Equipped with automatic cut-off and alarm systems for overload, short-circuit, and abnormal speed conditions to guarantee operational safety.
- Anti-Spill Soft Start: Engineered with a smooth start-up function to effectively prevent sample spillage during operation.
- Precision Monitoring: A high-contrast LCD screen displays real-time speed and torque, allowing for precise comparison between set values and actual performance.
- Constant Speed Control: Intelligent closed-loop control automatically adjusts torque to maintain constant speed even as sample viscosity changes.
- Remote Connectivity: Integrated RS232 data interface allows for connection to a PC for remote control and data logging.
- User-Friendly Chuck: Features a self-locking, keyless chuck design, allowing for tool-free installation of stirring impellers.
- Through-Shaft Design: The housing includes a pass-through hole for the stirring shaft, facilitating easy adjustment of impeller height and changing of mixing vessels.
- Versatile Compatibility: Supports a wide speed range (50-2200 rpm) and viscosities up to 10,000 mPas. Compatible with SUS304 Stainless Steel or PTFE-coated impellers.
| Specifications | |
| Power Supply | Single Phase AC100-240V, 50/60Hz, Approx. 70W |
| Operating Environment | Temp: 5~40°C, Relative Humidity: ≤80% |
| Stirring Capacity (H2O) | Max. 20L |
| Motor Rating (Input/Output) | Input: 60W / Output: 50W |
| Speed Range | 50 ~ 2200rpm |
| Speed Display | LCD |
| Speed Display Resolution | ±1 rpm |
| Max. Torque | 40N.cm |
| Safety Features | Overload Protection (LED Flash, Auto-stop); Motor Protection (LED Flash, Auto-stop) |
| Max. Viscosity | 10,000 mPas |
| Chuck Clamping Range | 0.5 ~ 10 mm |
| Data Interface | RS232 |
| Protection Class | IP42 |
| Equipment Dimensions (Main Unit) | Approx. L 186mm × W 83mm × H 220mm (Excluding stand) |
| Net Weight | Approx. 2.6kg (Main Unit Only) |
Operational Notes & Disclaimer
- Balancing: To prevent damage to the planetary gear system, ensure that the two mixing containers are perfectly balanced by weight before operation.
- Product Updates: Please note that product images, descriptions, and technical parameters are for reference only. Due to continuous product improvement, specifications are subject to change without prior notice. Please confirm the latest details with our sales team before ordering.
