Features
- High-Efficiency Processing: Achieves dispersion, mixing, agitation, and granulation functions within a short cycle time.
- All-in-One Versatility: A single machine capable of performing dispersion, mixing, compounding (kneading), granulation, and particle coating.
- Optimized Vessel Design: The granulation tank is free of unnecessary internal obstacles, minimizing material adhesion. This ensures ideal 3-dimensional particle movement and makes the unit easy to disassemble and clean.
- Wide Particle Size Range: Capable of handling spherical granulation for materials ranging from ultra-fine powders (nano-scale) to several millimeters (\mu m to mm range).
- User-Friendly Control: Features a low barrier to entry for operation. Equipped with a programmable PLC control system, allowing for precise, flexible, and automated adjustment of process parameters.
- Wear-Resistant Construction: Both the granulation tank interior and the agitator blades are constructed from Stainless Steel 304 and spray-coated with Tungsten Carbide for superior durability and wear resistance.
| Specifications | |
| Power Supply | 3-Phase 5-Wire, AC380V ±10%, 50Hz. Power: Approx. 5.5 KW |
| Construction Material | Powder contact parts spray-coated with Tungsten Carbide;
Inner surfaces Tungsten Carbide coated. (Coating materials can be customized upon request) |
| Roto Speed | 1400rpm |
| Vessel Inner Diameter | φ350mm |
| Reference Batch Capacity | 3-5 kg |
| Total Chamber Volume | Approx. 33L |
| Granulation Tank Size | Approx. Diameter 360 mm x Height 200 mm |
| Equipment Dimensions | Approx. L 1200mm x W 1000mm x H 1200mm |
| Net Weight | Approx. 367kg |
Operational Notes & Disclaimer
- Balancing: To prevent damage to the planetary gear system, ensure that the two mixing containers are perfectly balanced by weight before operation.
- Product Updates: Please note that product images, descriptions, and technical parameters are for reference only. Due to continuous product improvement, specifications are subject to change without prior notice. Please confirm the latest details with our sales team before ordering.
