Plunger Pump Slurry Feeding Device-MSK-151-L500

Application range: MSK-151-L500 drives the piston via a motor to extrude the coating evenly. It can be used in conjunction with roll-to-roll coating machines and other coating equipment. It is suitable for laboratories to explore product processes.

Model: MSK-151-L500
Dimension: About L561*W229*H271mm
Net weight: About 18Kg

Category: Feeding Device

Features:

Simple in structure and easy to operate;
Adjustable feeding speed;
Suitable for laboratory use.

Technical Specification
Power	Single Phase AC100-220 V±10%, frequency 50/60Hz, power 120W
Speed range	0.17-20ml/s (syringe piston speed)
Coating capacity	≤500ml per time
Pipeline	Teflon tube, 8mm ID, 10mm OD
Dimension	About L561W229H271mm
Weight	About 18Kg
Warranty	1 year
