Features:
- Precise screw‑pump feeding, equipped with one set of agitated buffer tank.
- Servo motor controls the rotational speed of the screw pump for adjustable flow rate, which can match the flow requirement of coating equipment.
- Corrosion‑resistant piping is compatible with various acidic and alkaline slurries. Pipe material can be optionally selected per customer requirements.
- Compact footprint and easy maintenance. When used with Kejing coating machines, linkage control with the coater can be realized.
- Stand‑alone control with touch‑screen operation for user‑friendly handling.
- Buffer tanks of different volumes are available as options.
- Filter device is optional.
| Specifications: | |
| Power Supply | Single-phase AC220V±10%, frequency 50/60Hz, power 500W |
| Air Supply | 0.5‑0.8 MPa compressed air or inert gas |
| Feeding Pump | 2NBL04F、2NBL06F、2NBL08F BingShen screw pump, select according to coating requirements |
| Feeding Flow | Servo‑motor driven, adjustable speed |
| Stirring Method | Pneumatic motor driven anchor‑type agitator with adjustable stirring speed |
| Buffer tank | SUS304 stainless steel; Optional effective volume: 12L、15L、20L、40L |
| Dimension | a) Optional 12L buffer tank: About L882*W468*H870mm
b) Optional 15L buffer tank: About L882*W468*H900mm c) Optional 20L buffer tank: About L882*W468*H1000mm d) Optional 40L buffer tank: About L882*W468*H1045mm |
| Weight | About 85Kg |
| Warranty | 1 year |
