Features：
- The agitator adopts twist‑type impeller; impellers of other sizes and shapes are optional.
- The tank bottom uses elliptical head for smooth material outflow and minimal residue
casters are equipped at the bottom for easy mobility.
- The top cover and tank body are made of SUS304. Both inner and outer surfaces of tank liner are polished by automatic polishing machine for convenient feeding and cleaning.
- Silicone rubber sealing ring is applied between top cover and tank body. Shaft dynamic seal adopts vacuum ferrule seal; other static‑position seals adopt silicone rubber sealing rings.transportation.
| Specifications |
| Power Supply | Single‑phase AC220V, 50/60Hz, power approx. 400W |
| Design Volume | Approx. 21L |
| Effective Volume | Approx. 15L |
| Tank Dimension | Diameter approx. 300 mm, depth approx. 300 mm, single‑layer tank (depth excludes elliptical bottom section) |
| Applicable Viscosity | 0‑10000 CPS |
| Vacuum Degree | -96 kPa |
| Positive Pressure | ≤0.1 MPa |
| Tank Bottom Head | Elliptical head for smooth material outflow and minimal residue |
| Tank Ports | Vacuum port: 1‑pc 1/4‑inch ball valve, SUS304Liquid feeding port: 1‑pc 1/4‑inch ball valve, SUS304Sight window: 2‑pc Φ50 mm, SUS304Discharge valve: 1‑pc 3/4‑inch ball valve, SUS304 |
| Agitation Unit | Fully‑enclosed gearbox; transmission bearing: NSK (or equivalent grade).Twist‑type impeller, SUS304 material. |
| Brushless Variable‑speed Motor | Type 60, power approx. 400W |
| Agitator Speed | Manual forward/reverse rotation supported.Speed range: 2‑60 rpm (long‑term operation recommended: 8‑40 rpm), adjusted by potentiometer. |
| Equipment Dimensions | Approx. L400 mm × W400 mm × H780 mm (subject to actual product) |
| Weight | Approx. 28 kg (subject to actual product) |
