Functional Features
- Centrifugal force from rotation and convection generated by revolution homogenize sample materials.
- Contact-free design without mixing blades to minimize contamination.
- Mixing, dispersion and defoaming are performed simultaneously.
- Achieve homogeneous mixing without shearing materials.
- Process up to six samples at the same time.
- Two operation modes: automatic and manual; 6 sets of operation profiles can be stored under automatic mode.
- Outer observation window made of transparent high-strength tempered glass to prevent window deformation.
- External compressed-air supply can be connected for rapid chamber cooling.
- External vacuum pump can be connected to provide vacuum mixing environment for the chamber.
Specifications
| Power Supply | Single-phase AC220V, 50Hz, power approx. 450 W |
| Mixing Method | Planetary centrifugal mixing |
| Standard Container | 30 ml ×6 (Φ38 mm × H35 mm) |
| Max Processing Capacity | 15 mL ×6 (Material weight varies under identical volume due to different material densities) |
| Working Principle | Planetary-gravity mixing / defoaming with fixed rotation-to-revolution ratio of 0.6 |
| Revolution | Variable speed (200-2000 rpm); arbitrary input, resolution: 1 rpm |
| Rotation | 0.6 times of revolution speed |
| Max Speed | 2000 rpm |
| Drive Mode | 400 W motor |
| Stored Parameter Sets | 6 groups |
| Vacuum | External vacuum pump |
| Balance Adjustment | Self-balancing (No counterweight adjustment required) |
| Setting Time | Three-segment programmable, 200 s per segment, total 600 s (resolution: 1 s). (In automatic mode: To prevent vessel over-heating and melting: max. 150 s per segment for 1450-1800 rpm; max. 50 s per segment for speed＞1800 rpm.) (In manual mode: When speed＞1800 rpm, single-run maximum runtime is 120 s. A 120-second cooling countdown will start automatically upon completion of operation.) |
| Control System | Dual closed-loop PLC control, Chinese UI, touch-screen operation |
| Lubrication System | Bushing splash-proof structure, passive lubrication to prevent bearing wear |
| Main Alarm Functions | Unbalanced condition / Upper cover unclosed / Overload |
| Main Safety Functions | Automatic stop upon fault; upper-cover auto-lock during operation |
| Transmission Type | Gear drive |
| Equipment Dimensions | Approx. W310 mm × D430 mm × H450 mm (including protruding parts, subject to actual product) |
| Weight | Approx. 45 kg (subject to actual product) |
