Features
- Superior Mixing Homogeneity: Achieving a high degree of uniformity, the system induces macroscopic vertical tumbling and horizontal convection, while simultaneously performing microscopic intercalation and shearing between particles.
- Dual-Action Efficiency: The mixing process is accelerated by two simultaneous movements (vessel rotation and internal blade rotation), which mutually enhance the blending action for optimal efficiency.
- Optimized for Ultra-Fine Powders: Specifically designed to handle ultra-fine powders that are prone to floating or segregation. The equipment generates low mechanical impact and friction, effectively suppressing the floating, adsorption, and electrostatic repulsion often seen in fine materials.
- Effective Light/Heavy Powder Integration: The internal rotating blades are engineered to pull floating “light” powders down into the “heavy” powder bulk, ensuring thorough integration of materials with different densities.
- Non-Destructive Mixing: The low-speed, multi-directional shear mixing preserves the integrity of the material. There is no high-speed impact or collision, ensuring the original particle morphology remains virtually unchanged.
- High Loading Capacity: The efficient vessel design allows for a loading coefficient (fill ratio) of up to 80%.
| Specifications | |
| Power Supply | Single-Phase AC220V ±10%, 50Hz, Power: Approx. 250W |
| Mixing Vessel | Standard: 5L (Optional: 2L, 3L, 4L) |
| Mixing principle | Cross-Shaft Dual-Motion Mixing (Vessel Rotation + Internal Agitation) |
| Timer Setting | 0 – 999 minutes, Automatic Stop |
| Loading Coefficient | 80% |
| Max. Loading Weight | 5 kg |
| Vessel Rotation Speed | 0 – 28 rpm (Adjustable) |
| Internal Blade Speed | 2.5 x Vessel Rotation Speed
(Synchronized) |
| Vessel Material | Stainless Steel 304 |
| Vessel Wall Thickness | 2.0 mm |
| Blade & Support Material | Stainless Steel 304 |
| Inlet & Outlet Size | 72 mm |
| Equipment Dimensions | Approx. L 380mm × W 296mm × H 480mm (Excluding protrusions) |
| Net Weight | Approx. 35kg |
Operational Notes & Disclaimer
- Balancing: To prevent damage to the planetary gear system, ensure that the two mixing containers are perfectly balanced by weight before operation.
- Product Updates: Please note that product images, descriptions, and technical parameters are for reference only. Due to continuous product improvement, specifications are subject to change without prior notice. Please confirm the latest details with our sales team before ordering.
