Functional Features
- The equipment utilizes electronic constant force speed regulation, with a digital display of the rotating shaft speed;
- Stirring time can be set as a timing function or a counting (cumulative time) function;
- Uses a brushed motor, featuring high rotational speed and excellent dispersion/mixing results;
- Manual lifting of the machine head, offering simple operation;
- Stable performance, reliable, and durable;
- Standard configuration includes three dispersing discs, which can be interchanged according to different experimental needs. The dispersing discs can perform high-speed shearing, impacting, crushing, and dispersing of materials to achieve states of dissolution, dispersion, and refinement;
- SUS304 dispersing discs: high strength, sturdy and durable, easy to replace, easy to clean, and non-polluting.
Specifications
| Power Supply | Single-phase AC220V, Frequency 50Hz, Power approx. 1.2KW |
| Motor Power | 1.1KW |
| Medium Viscosity | Below 15000cp |
| Speed Range | 100–8000r/min |
| Dispersing Disc Diameter | Standard configuration includes one each of 50mm / 60mm / 80mm; Material: 304 Stainless Steel |
| Standard Material Tank | Includes one each of 3L / 1.5L; Material: 201 Stainless Steel |
| Equipment Dimensions | Approx. L 460mm x W 420mm x H 800mm |
| Net Weight | Approx. 25KG |
Operational Notes & Disclaimer
- Balancing: To prevent damage to the planetary gear system, ensure that the two mixing containers are perfectly balanced by weight before operation.
- Product Updates: Please note that product images, descriptions, and technical parameters are for reference only. Due to continuous product improvement, specifications are subject to change without prior notice. Please confirm the latest details with our sales team before ordering.
