Features
- Adopts slot die coating process, featuring high coating precision, excellent consistency and a broad coating window.
- Sheet‑type slot die coating delivers high coating precision and good consistency.
- Suitable for low‑viscosity slurries and thin‑film coating processes.
- Low consumption of slurry and substrate, user‑friendly, ideal for process validation.
- Coating substrate is equipped with vacuum adsorption function; vacuum pump is included as standard.
- Coating substrate comes with heating function with controllable temperature.
- Multiple coating processes are optional.
- Air‑knife module is optional for perovskite coating.
- Special coating plates are optional for separator coating.
- Compatible for operation inside glove box.
- Compliant with UL certification standards.
| Specifications | |
| Power Supply | Single-phase AC110-220V±10%, 50/60Hz, 280W |
| Coating Method | Slot die coating |
| Coating Thickness | ±1μm |
| Die Head | Brand: Domestic
Type: Single‑layer coating Die cavity: Semi‑circular single cavity Shims: 3 pcs as standard |
| Die Head Movement | 0.05‑20 mm/s (moving speed of extrusion coating head) |
| Die Head Feeding | Speed: 0.05‑5 ml/s
Die cavity volume (single cavity): approx. 2.6 ml |
| Die Head Adjustment | Adjustment range: 0‑5 mm
Adjustment mode: Manual adjustment with digital micrometer head, display precision 1μm |
| Coating Dimension | Max. L100 × W100 mm |
| Substrate Plate Precision | 6μm flatness at room temperature |
| Minimum Material Loss | Approx. 12 ml |
| Substrate Plate Temperature | Max. 120 °C (heating time over 30 minutes) |
| Substrate Plate Size | L150 × W130 mm |
| Equipment Dimensions | Approx. L450ｘW360ｘH450mm |
| Weight | Approx. 20 kg |
