Features
- It adopts slot‑die coating process, featuring high coating accuracy, good consistency and a wide coating window.
- Feeding is realized by syringe pump. The feeding system is sealed from external interference, with low material consumption and minimal waste.
- The temperature of the feeding pump is controllable to achieve hot‑melt material feeding.
- The coating die head is temperature‑controllable, and the internal channel geometry can be customized according to material requirements.
- The coating substrate stage is a vacuum chuck with built‑in vacuum pump.
- This equipment can be operated inside a glove box.
- The coating die and feeding system are easy to disassemble and clean.
- Equipped with touch‑screen operation, it enables convenient and quick adjustment, saving and control of equipment parameters.
| Specifications | |
| Power Supply | Single-phase AC220V±10%, 50/60Hz (AC110V customizable), 450W |
| Coating Size | Max. L300×W200 mm (Standard) |
| Substrate Plate Size | L360×W250 mm |
| Mechanical Speed | 0.05‑20 mm/s (Slot‑die head travel speed) |
| Substrate Thickness | Max: 5mm |
| Syringe Volume | Max. 75 ml (Stainless‑steel syringe) |
| Feeding Rate | 0.05‑5 ml/s (syringe piston speed) |
| Feeding Temperature | Max. 100 °C |
| Coating Head | Material: 310S |
| Dimension: L240×W50×H24 mm | |
| Die cavity: Cylindrical, coat‑hanger, teardrop types, optional | |
| Max. 200 mm, adjustable by replacing shims | |
| Temperature‑controllable, Max. 100 °C | |
| Shims | 1 set supplied as standard; thickness and slot opening dimension to be specified by customer |
| Die Head Adjustment | Manual adjustment, dial indicator resolution 1 μm |
| Equipment Dimensions | Main unit: L760xW520xH720mm
External vacuum pump assembly: L150 × W100 × H150 mm |
| Weight | Approx. 100 kg |
