Features
- Sheet‑type slot die coating features high coating precision and excellent consistency.
- Suitable for low‑viscosity coatings and thin‑film coating processes.
- Low consumption of coating material and substrates, easy‑to‑use, ideal for process verification.
- Coating substrate is equipped with vacuum adsorption function, with vacuum pump as standard.
- Capable of operation inside a glove box.
- Multiple coating processes are available as optional configurations.
- Air knife module is optional for perovskite coating.
- Heating function is optional for the coating substrate with controllable temperature.
- Special coating plates are optional for separator coating.
| Specifications | |
| Power Supply | Single-phase AC110-220V±10%, 50/60Hz, 200W |
| Coating Method | Slot die coating |
| Coating Thickness | ±1μm |
| Die Head | Brand: Domestic
Die cavity: Semi‑circular single cavity Shims: 3 pcs as standard |
| Die Head Movement | 0.05‑20 mm/s (moving speed of extrusion coating head) |
| Die Head Feeding | Speed: 0.1‑1.5 ml/s
Die cavity volume (single cavity): approx. 8 ml |
| Die Head Adjustment | Adjustment range: 0‑5 mm
Adjustment mode: Manual adjustment via micrometer, display accuracy: 1μm |
| Coating Dimension | Max. L300 × W200 mm |
| Substrate Plate Precision | 20μm flatness at room temperature |
| Minimum Material Loss | Approx. 18 ml |
| Substrate Plate Temperature | Max. 100 °C (heating time over 30 minutes) (Optional power: 1.2 kW) |
| Substrate Plate Size | L360 × W250 mm |
| Equipment Dimensions | Approx. L760ｘW520ｘH430mm |
| Weight | Approx. 100 kg |
