Micro-Vibration Mill with Grinding Tubes – MSK-SFM-12M

Micro-Vibration Mill with Grinding Tubes – MSK-SFM-12M

Application range:

MSK-SFM-12M is a micro-vibration ball mill and mixer specially developed and designed for high-intensity uniform mixing of samples. Three samples can be mixed simultaneously in 2ml disposable screw microtubes (usually completed in 45 seconds). This product is compact, convenient, economical and practical, making it an ideal choice to replace traditional high-priced mixers.

Model:

MSK-SFM-12M

Dimension:

About L170mm*W210mm*H155mm

Net weight:

About 2.2Kg

Categories: ,
Share your love

Features

  • Compact in design, convenient and easy to carry, attractive appearance, which is suitable for small quantities of samples.
  • Automatic alarm reminders and power-off when the door is opened to ensure experimental safety.
  • Used for both ball milling and mixing.
  • Placed in a glove box with an argon atmosphere for use.
  • Low noise and easy to operate.

Specifications

Working Voltage Single phase AC220V±10%, frequency 50Hz, power about 40W
Vibration Speed 2800-5000rpm (adjustable)
Timer 3-180s (adjustable)
Tube Material PE
Tube Size φ10mm*H45mm
Tube Volume 3*2ml
Standard 2ml * 50 pcs milling tube (Milling balls are not included)
Milling Media High-purity zirconia balls, which can withstand high impact strength and high-speed grinding
Standard accessories: a tube of φ0.1mm, 0.5mm, 1.0mm, 1.5mm, 3.0mm balls for each
Customized zirconia balls are available upon request at extra cost
Dimension About L170mm*W210mm*H155mm
Weight About 2.2Kg
Warranty 1 year
